MAZDA Main Shaft B1600

Description

Purpose-built main shaft for the B1600 manual gearbox. Critical splines, journals, and shoulders are machined to OE geometry to carry the 1st–5th/Reverse gears and synchronizers and transmit torque to the output section. Manufactured from alloy case-hardening steel, carburized & quenched and precision-ground for controlled concentricity and runout, it delivers stiffness, durability, and low NVH over long duty cycles. Installs as a true drop-in; best serviced together with bearings, seals, and synchronizer components.

Specification

Teeth Count: 32 / 32 / 31 / 25 T

Interfaces: Front/rear splines and synchronizer shoulders to OE spec

Material: Alloy case-hardening steel, SCM415 / SAE 8620 (or equivalent)

Heat Treatment: Carburized & quenched

Surface Hardness: HRC 58–62 (tough core retained)

Manufacturing: CNC machining; journals & locating faces precision-ground; spline rolling/broaching; deburring
