Description

The AX15-36 is a key synchronizer component for 1st and 2nd gear in the Aisin AX15 5-speed manual transmission. It connects the mainshaft and gears through a sliding mechanism, working with synchro rings to ensure smooth and precise shifting.

Made from high-strength carburized alloy steel (e.g. SAE8620), it features surface hardness of HRC 58–62 for excellent wear resistance and durability. Precision-cut internal splines and outer engagement teeth provide accurate fit with the mainshaft, synchro rings, and gears.

Commonly used in Jeep Wrangler, Cherokee, Comanche, and Grand Cherokee (1988–1999) with AX15 transmissions, and compatible with some Toyota R151/R154 models (tooth profile confirmation required).

Specification

Material : SAE8620 or SAE4320H

Heat Treatment : Carburized and quenched

Surface Hardness : HRC 58–62

Tooth Count : 37T / 42-6T

Internal Structure : Precision spline for mainshaft engagement

External Structure : Engagement teeth for synchro ring and gear coupling

Weight : Approx. 220–260 g (subject to actual part)

Compatible Vehicles :

• Jeep Cherokee XJ (1989–1999, selected 4.0L models)

• Jeep Comanche MJ (1989–1992)

• Jeep Wrangler YJ / TJ (1989–1999, 4.0L I6 engine)

• Jeep Grand Cherokee ZJ (early 4.0L manual transmission models)

• Dodge Dakota (select 1990s models with 3.9L / 5.2L manual transmission)

• Dodge Ram 1500 (1994–1996, manual transmission models)
