Gear Shaping Process

Gear Shaping Process
Our gear shaping technology meets the demands of precision gear machining, offering versatility for different tooth profiles and pitches, particularly ideal for internal gear machining.
Key Features of Gear Shaping Machines
Versatile Machining Capabilities
Supports internal gears, external gears, splined shafts, and sprockets.
Suitable for spur gears, helical gears, and custom tooth profiles.
High-Precision Machining
Rigid structural design and precision transmission systems ensure gear accuracy up to ISO 5 Grade.
Equipped with an advanced CNC system for high-precision compensation and stable processing.
Flexible Processing
Ideal for small-batch production, customized gears, and high-efficiency mass production.
Supports multi-process machining, reducing workpiece handling and alignment errors.
Wide Material Compatibility
Capable of machining steel, stainless steel, aluminum alloys, plastics, and high-strength alloys.
Technical Specifications
Maximum Outer Diameter: Up to 800 mm
Internal Diameter Range: From 50 mm
Module Range: 0.5 - 8 mm
Maximum Gear Width: 150 mm
Machining Accuracy: ISO 5 Grade / DIN 6 Grade
Maximum Stroke: 200 mm
