AX15/R151 1st Gear

Description

The AX15-10 1st gear is a key low-speed, high-torque gear used in the AX15 5-speed manual transmission. Made from SAE 8620 or SAE 4320H carburized alloy steel, it offers excellent strength, impact resistance, and surface hardness of HRC 58–62. The helical gear design ensures smooth, quiet operation and improved durability. Precision-machined splines and gear teeth provide perfect fit with the input and main shafts, reducing wear and power loss. Compatible with synchronizer rings and shift sleeves, it is ideal for OE replacement or performance upgrades.

Specification

Gear Type : Helical Gear

Tooth Count : 23T

Surface Hardness : HRC 58–62

Internal Structure : Precision spline (mates with input shaft)

Material : SAE8620 or SAE4320H

Heat Treatment : Carburized and quenched

Manufacturing Process : Precision gear hobbing and spline cutting to ensure high concentricity and accurate gear engagement

Compatible Vehicles :

• Jeep Cherokee XJ (1988–1999, 4.0L I6)

• Jeep Wrangler YJ (1989–1995, 4.0L I6)

• Jeep Wrangler TJ (1997–1999, early models, 4.0L I6)

• Jeep Comanche MJ (1989–1992)

• Dodge Dakota (1992–1996, selected 3.9L / 5.2L manual models)

• Dodge Ram 1500 (early models equipped with AX15 transmission)

• Nissan 240SX / Silvia (S13/S14) – commonly used in motorsport applications with AX15 transmission conversions

  • Model:AX15-10
