TOYOTA 3rd Gear

Description

Direct-replacement 3rd-speed gear for Toyota manual transmissions referencing OE 33034-36090. Manufactured from case-hardening alloy steel, carburized & quenched, and precision-hobbed with refined dog teeth for quiet meshing, high load capacity and long service life. Bore and locating faces are precision-ground and all tolerances are held to OE spec for a true drop-in fit.

Specification

Gear Form: Helical

Material: SCM415 / SAE 8620 alloy case-hardening steel (or equivalent)

Heat Treatment: Carburized & quenched

Surface Hardness: HRC 58–62

Manufacturing: CNC turning/milling, precision gear hobbing, dog-tooth finishing & deburring; precision-ground bore and faces
