AX15/R151 1st & 2nd Gear Synchro Slider

Description

The AX15-15B synchro slider is designed for the 1st and 2nd gear positions in Jeep AX15 manual transmissions. It plays a key role in the synchronizer assembly by engaging with the synchro rings to match gear and shaft speeds during shifting, ensuring smooth engagement and reducing gear wear.

Made from high-strength carburized alloy steel (SAE 8620 / SAE 4320H), this slider offers excellent durability and wear resistance. Heat-treated to HRC 58–62, it withstands heavy loads and continuous operation. Precision-machined internal splines and outer teeth ensure a perfect fit with the main shaft and synchro rings.

Fully compatible with OE specifications, the AX15-15B is ideal for transmission rebuilds or performance upgrades.

Specification

Material : SAE8620 or SAE4320H

Heat Treatment : Carburized and Quenched

Surface Hardness : HRC58–62

Tooth Design : Internal Splines + External Synchro Teeth (engages with synchro rings)

Tooth Count : 39-6T

Machining Process : Precision gear hobbing and spline cutting

Compatible Vehicles:

• Jeep Cherokee XJ (1989–1999, 4.0L I6)

• Jeep Wrangler YJ (1989–1995)

• Jeep Wrangler TJ (1997–1999)

• Jeep Comanche MJ (1989–1992)

  • Model:AX15-15B
