Toyota - R154 FullSet

Description

The R154 reinforced gear set is a high-performance upgrade solution designed to withstand high RPM and high torque output. This complete set includes the main shaft, input shaft, and 1st to 5th gears. All gears are manufactured from SAE 8620 or SAE 4320H carburized alloy steel, with a carburized and quenched surface treatment that achieves a hardness of HRC 58–62, significantly enhancing wear and impact resistance. Featuring precision-cut helical gear teeth and high-accuracy hobbing and grinding processes, the gear set delivers smoother power transmission while reducing noise and energy loss. It is especially suitable for modified applications that demand long-term durability under heavy loads and reinforced drivetrain structures. With an optimized design that balances strength, longevity, and installation compatibility, this gear set is the ideal choice for enhancing both the durability and performance of your transmission system.

Specification

Gear Type : Helical Gear

Surface Hardness : HRC 58–62

Material : SAE 8620 or SAE 4320H

Heat Treatment : Carburized & quenched

Manufacturing Process : Precision gear hobbing and grinding

Transmission Efficiency : High gear mesh accuracy design to reduce internal power loss

Included Components : NGT-R154-001 – Counter Shaft、NGT-R154-002 – Speed Gear、NGT-R154-003 – Input Shaft、NGT-R154-004 – 1st Gear、NGT-R154-005 – 2nd Gear、NGT-R154-006 – 3rd Gear、NGT-R154-007 – 5th Gear

Compatible Vehicles :
Suitable for vehicles equipped with the R154 5-speed manual transmission, such as the Toyota Supra MK3 (A70), Soarer (Z20), Chaser, Cresta, and Mark II. Commonly used in rear-wheel-drive performance builds requiring high torque capacity and enhanced durability.

  • Model:R154-SET
