Counter Shaft Mazda BT50

Description

OE-spec counter shaft for the Mazda BT-50 manual transmission. The integrated helical gear sections are precision-hobbed and edge-relieved, while the journals, bore, and locating faces are precision-ground to ensure quiet, rigid mesh and high efficiency across the ratios. Made from SCM415 / SAE 8620 alloy case-hardening steel and carburized & quenched to HRC 58–62 for superior wear and pitting resistance. Built to OE geometry and tolerances for true drop-in replacement during rebuilds.

Specification

Tooth Form: Helical

Tooth Count: 23/34/51T

Material: SCM415 / SAE 8620 alloy case-hardening steel (or equivalent)

Heat Treatment: Carburized & quenched

Surface Hardness: HRC 58–62

Manufacturing: CNC turning/milling; precision hobbing; deburring/edge-relief; journal & face precision grinding; dynamic balance check
