Toyota Forklift Transmission Counter Shaft

Description

Purpose-built countershaft assembly for the Komatsu FD25 forklift. The shaft and helical gears are machined as a single unit to OE ratios and geometry. Precision-hobbed teeth with edge relief and ground journals/faces deliver rigid mesh and low NVH under heavy-duty, low-speed cycles. Manufactured from SCM415/SAE 8620 alloy case-hardening steel and carburized & quenched to HRC 58–62 for superior wear and pitting resistance. Concentricity, runout, and lead/profile error are held to OE tolerances for a true drop-in during overhaul. Verify by transmission tag/VIN for year/version differences.

Specification

Tooth Count: Per OE specification

Material: SCM415 / SAE 8620 alloy case-hardening steel (or equivalent)

Heat Treatment: Carburized & quenched

Surface Hardness: HRC 58–62 (tough core retained)

Manufacturing: CNC turning/milling; precision hobbing; edge-relief deburring; journals & faces precision-ground

  • Model:KOM FD 25
